Product Name : The smartest mainstream CI Press
PHOENIX
Product Description

PHOENIX (The smartest mainstream CI Press)

As our best-selling CI flexographic press, Phoenix is equipped with the features most printers need. This includes fully servo-driven printing units, smart registration and impression control system, non-stop unwind and rewind units, ink viscosity control and automatic washing systems, as well as exceptional drying performance. Additionally, it is equipped with the latest smart production monitoring system, a digital Kanban system providing critical real-time press information and OEE reports to production managers and operators, enabling superior print production management. If you're looking for a high-performance CI flexo press equipped with an intelligent system, Phoenix will be your reliable production partner in the competitive market, helping you easily achieve exceptional quality and consistent profitability.

Specification Details
Specifications   PHOENIX SERIES
Number of Colors   6 / 8
Max Machine Speed m/min
ft/min
400
1312
Material Width mm
inch
870 / 1070 / 1270 / 1370
34.3 / 42.1 / 50 / 53.9
Printing Sleeve Width mm
inch
800 / 1000 / 1200 /1300
31.5 / 39.4 / 47.2 / 51.2
Roll Diameter mm
inch
800 / 1000 (Option)
31.5 / 39.4 (Option)
Repeat Length mm
inch
360~800
14.2~31.5
About
  • Non-stop turret type unwind and rewind
  • High-efficiency drying tunnel
  • Print and Anilox sleeve
  • Auto wash system
  • Auto registration system
  • Infeed web guide

Phoenix is a compact CI flexo press yet with spacious internal layout for ergonomic considerations. The job management touch screen system is available in 5 different languages. The movement of the plate and anilox assemblies are driven by servo motors, allowing fine movement tuning to 1 micron. The parameters of each print could be stored in the system for repeat orders. The Phoenix is designed for...

Operation Comfort

  • Touch screen interface
  • User friendly layout screen control
  • Fully digitalized controls for precise print settings
  • Easy access to printing stations

Print Quality

  • Heavy duty designed machine frames
  • Servo motor control guarantee excellent print registration holding
  • Web viewing system
  • Automated registration control
  • Micrometric kiss impression control to one micron

Quick job Change

  • Anilox and plate sleeve design
  • Auto pre-register control
  • Auto quick wash features for inking system
  • Job memory for repeat tasks

Smart Production Monitoring System

  • Digital kanban system for quick monitoring on production status including job information, printing setup, ink management, and auto splicing.
  • Easier for operators and executives to supervise multiple priting line.
  • Production analysis records on machine OEE utilization rate, daily output etc, able to export production data in a form of report.
  • Live view during auto splicing and auto wash, with ink supply control, such as viscosity and temperature.
  • Industrial standard tablet computer for wireless control. A more flexible, and efficient way of operating.

Remote Service Assistance

  • 24/7 machine online diagnostic system
  • Exclusive PLC Network Connection Technology to achieve deep online diagnose and prompt remote-maintenance.

Industrial I4.0

  • OPC UA Data Exchange Protocol for communication between devices, machines and enterprise systems (ERP, SCADA, CRM…etc)
  • Remote HMI monitoring via mobile devices

Safety

  • Compliant with Conformité Européene or Australian Standard
  • Certification service available with CSA, NEC and IEC

Paper

Food packaging, Medical packaging, Pre-print for paper box, Bags, Paper cup, Liquid & beverage, Household cleaning, Cosmetics, Gift wraps, Wallpaper

Film

Food packaging, Medical packaging, Industrial packaging, Sanitary Packaging, Bags, Liquid & beverage, Household cleaning, Cosmetics, Confectionary wrappers

Aluminum

Food packaging, Medical packaging, Industrial packaging

Woven bag
